Aqua Source Synergy 55 Drum Filter


The Synergy 55 offers ultra efficient mechanical filtration, allowing virtually maintenance free cleaning of your biological filter.

Built to a very high standard, the filter features the following;

  • Flow rate of 12,100 gallons per hour
  • 4 x 110mm inlets and 2 x 110mm outlet
  • Dry run protection
  • 70 micron screen with Blanketweed and debris trap
  • 110mm descending waste gutter
  • Fully automatic Siemens Logo control panel, manually adjustable
  • Lid with safety cut off switch
  • Blanketweed and debris trap
  • 4 bar cleaning pump
  • 210nm ultra reliable motor
  • Direct drive
  • Filter can still be run if the motor fails
  • Full 12 month warranty ( exc. screen)
  • Dimensions— External ; 806mm x 776mm x 756mm ( LxWxH )
  • Drum Size—620mm (D) x 415 (W)

Maximum Water Level – 645mm

Installation height is 14.5cm above water level of the pond.

Synergy Drum Manual 2020
